Ultrasonic Testing

Detecting Internal Flaws & Measuring Material Thickness

Ultrasonic Testing

Ultrasonic Testing, also known as ultrasonic inspection, is an NDT service that can both detect flaws in a component and measure material thickness. Ultrasonic non-destructive testing makes use of sound waves to detect defects and It can be used on a variety of materials, such as steel, other metals and alloys.

The Benefits Of Ultrasonic Testing

  • Instant report on-site
  • Fully portable equipment
  • On-site inspections
  • Detailed flaw detection
  • Bond integrity assessment
  • A high degree of accuracy

How can we help you?

Contact us today to find out how Capital NDT can help you with our wide range of Non Destructive Testing Services.

What Is Ultrasonic Testing

Ultrasonic Testing is a non-destructive testing method that makes use of short wavelength sound waves of both high and low frequency to detect internal flaws and defects within components and parts. Additionally, it can be used to determine a material’s thickness. For example, the thickness of the wall of a pipe.

What Ultrasonic Testing Is Used For

Ultrasonic testing is used to test for internal defects and flaws in castings, welds, tubes, pipes and composite materials in a wide range of industry sectors. Ultrasonic testing is used to detect flaws such as inclusions, cracks and porosity. It is especially useful at detecting small flaws or defects that are located deep within a part.

Ultrasonic testing is also used to assess the integrity of a bond between two materials. The benefits of this NDT method is that it provides quick and accurate results and is very portable, making it especially useful for on-site testing and inspection.

Ultrasonic weld testing

By making use of angled transducers we are able to inspect any welds of a test object. Sound waves are sent into both the parent material as well as the weld volume. This generates geometric responses from the cap and root regions of the weld, which allows us to look for deviations in these signals.

Measuring material thickness

Ultrasonic testing can also be used to measure material thickness. Sound waves travel at different velocities within different materials. By knowing the material velocity and the time it takes for a sound wave to travel from the transducer through the material and back again our expert inspectors can calculate the thickness of the material.

How Ultrasonic Testing Works

The technique of ultrasonic testing makes use of a pulser/receiver unit to power an ultrasonic transducer. This transducer is placed in contact with the material or component that is being tested and generates pulsed sound waves into the object.

The reflected sound waves or echos are received back by the transducer and any internal discontinuities will cause the signals to be displayed on the display unit. Our skilled investigators will then interpret these signals to determine if there are any flaws or defects present in the material.

Ultrasonic testing provides a high degree of accuracy when determining the size and shape of any flaws or defects. This testing method also has the ability to locate sub-surface defects and provides far better depth penetration than other non-destructive testing methods.

Ultrasonic Inspection

NDT Services Available On Site Across The UK

Our team of qualified NDT technicians are able to carry out Ultrasonic Testing directly at our customers’ premises with our range of state of the art ultrasonic testing equipment. We can perform NDT inspections on-site across the UK as well as at our laboratory and testing facility in Colnbrook, just off the M25.

Our team of NDT technicians are all qualified in accordance with BS EN ISO 9712 with industry recognised PCN (Personnel Certification in Non-Destructive Testing). Here at Capital NDT, we are also accredited with a number of well-known bodies, including SAFed and Adips.

For More Information On Our NDT Inspection Services

For more information on our Ultrasonic Testing service or any of our other Non-Destructive Testing services contact our team by calling us on 01753 6844 896 or by filling out our contact form
